Map Generator With Markers by Apoth3osis

Name: Map Generator With Markers
Brand: Apoth3osis
SKU: 695e8767c309cf48479329e6
Price: 0.20 USD
Availability: InStock

Map Generator With Markers

Function

Available ActionsEach successful request consumes credits as outlined below.

create_map^20cr

Details

Generate custom static map with markers and optional paths connecting points. This tool creates map images with multiple markers that can be customized with colors, labels, and sizes, supports drawing paths between points with configurable colors and weights, offers multiple map types including roadmap, satellite, hybrid, and terrain views, allows precise zoom control and high DPI scaling for better image quality, and automatically stores generated images in cloud storage with 7-day expiration. Perfect for creating location-based visualizations, route maps, and geographic data presentations without requiring interactive map embedding.

Use Cases

Creating route maps with waypoints, Generating location markers for reports, Visualizing geographic data distributions, Creating satellite view property maps, Building delivery route visualizations, Generating maps for presentations, Creating location-based infographics, Documenting field service locations, Visualizing travel itineraries, Creating real estate location maps

Dynamic MCP Setup

Connect once through AgentPMT Dynamic MCP, then use approved tools from the same agent connection.

30 Second Setup

STDIO connector for Claude Code, Codex, Cursor, Zed, and other LLMs that require STDIO or custom connections.

npm install -g @agentpmt/mcp-routeragentpmt-setup

Hosted Streamable HTTPS

MCP endpoint for browser-based apps like ChatGPT, Claude, Grok, or any time you want a streamable connection with no local install.

https://api.agentpmt.com/mcp

Config Example

Use the hosted endpoint directly in clients that support remote MCP. Store your Bearer token in the client config or secret field.

Full connection guide

{
  "mcpServers": {
    "agentpmt": {
      "type": "streamable-http",
      "url": "https://api.agentpmt.com/mcp",
      "headers": {
        "Authorization": "Bearer <AGENTPMT_BEARER_TOKEN>",
        "x-instance-metadata": "{\"client\":\"generic-mcp\",\"platform\":\"remote\"}"
      }
    }
  }
}

Need client videos, organization controls, audit details, and the full feature overview?

More About Dynamic MCP

Actions(1)

create_map^20cr11 params(1 required)

Generate a static map image with markers plotted at specific coordinates, with optional path connecting points.

pointsrequiredarray

Points to plot as markers. Each point requires latitude and longitude coordinates.

Array of: object

map_typestring

Map type to display

Values:

roadmapsatellitehybridterrain

Default: roadmap

image_widthinteger

Image width in pixels (max 640)

Default: 640

Range: 1 - 640

image_heightinteger

Image height in pixels (max 640)

Default: 640

Range: 1 - 640

scaleinteger

Scale factor for high DPI displays (1 or 2)

Default: 1

Range: 1 - 2

zoominteger

Zoom level (0-21). Auto-calculated if omitted when markers/path are provided.

Range: 0 - 21

draw_pathboolean

Connect points with a path line. Requires at least 2 points.

Default: false

path_colorstring

Path color in hex format (e.g., 0x0000ff for blue)

Default: 0x0000ff

path_weightinteger

Path line weight in pixels

Default: 5

Range: 1 - 20

marker_colorstring

Default marker color name or hex for all points (overridden by per-point color)

marker_sizestring

Default marker size for all points (overridden by per-point size)

Values:

tinysmallmid

curl -X POST "https://api.agentpmt.com/products/purchase" \
  -H "Content-Type: application/json" \
  -H "Authorization: Bearer ********" \
  -d '{
    "product_id": "695e8767c309cf48479329e6",
    "parameters": {
      "action": "create_map",
      "points": [],
      "map_type": "roadmap",
      "image_width": 640,
      "image_height": 640,
      "scale": 1,
      "draw_path": false,
      "path_color": "0x0000ff",
      "path_weight": 5
    }
  }'

import requests
import json

url = "https://api.agentpmt.com/products/purchase"

headers = {
    "Content-Type": "application/json",
    "Authorization": "Bearer ********"
}

data = {
    "product_id": "695e8767c309cf48479329e6",
    "parameters": {
        "action": "create_map",
        "points": [],
        "map_type": "roadmap",
        "image_width": 640,
        "image_height": 640,
        "scale": 1,
        "draw_path": false,
        "path_color": "0x0000ff",
        "path_weight": 5
    }
}

response = requests.post(url, headers=headers, json=data)
print(response.status_code)
print(response.json())

const url = "https://api.agentpmt.com/products/purchase";

const headers = {
  "Content-Type": "application/json",
  "Authorization": "Bearer ********"
};

const data = {
  product_id: "695e8767c309cf48479329e6",
  parameters: {
    "action": "create_map",
    "points": [],
    "map_type": "roadmap",
    "image_width": 640,
    "image_height": 640,
    "scale": 1,
    "draw_path": false,
    "path_color": "0x0000ff",
    "path_weight": 5
  }
};

fetch(url, {
  method: "POST",
  headers,
  body: JSON.stringify(data)
})
  .then(response => response.json())
  .then(data => console.log(data))
  .catch(error => console.error("Error:", error));

const axios = require('axios');

const url = "https://api.agentpmt.com/products/purchase";

const headers = {
  "Content-Type": "application/json",
  "Authorization": "Bearer ********"
};

const data = {
  product_id: "695e8767c309cf48479329e6",
  parameters: {
    "action": "create_map",
    "points": [],
    "map_type": "roadmap",
    "image_width": 640,
    "image_height": 640,
    "scale": 1,
    "draw_path": false,
    "path_color": "0x0000ff",
    "path_weight": 5
  }
};

axios.post(url, data, { headers })
  .then(response => {
    console.log(response.status);
    console.log(response.data);
  })
  .catch(error => {
    console.error("Error:", error.message);
  });

Login to view your API and budget keys. The example above uses placeholder values. Sign in to see personalized code with your bearer token.

Usage Instructions

Usage guidance provided directly by the developer for this product.

Map Generator With Markers

Generate static map images with custom markers and optional connecting paths between points.

Actions

create_map

Generate a static map image with one or more markers plotted at specific coordinates.

Required Fields:

points (array): One or more point objects to plot. Each point requires:
- latitude (number): Latitude coordinate (-90 to 90)
- longitude (number): Longitude coordinate (-180 to 180)

Optional Point Fields:

label (string): Single character A-Z or 0-9. Only displayed on default/mid size markers.
color (string): Marker color name or hex code (e.g., "red", "blue", "0xFFFF00")
size (string): Marker size -- "tiny", "small", or "mid"

Optional Map Fields:

map_type (string): "roadmap" (default), "satellite", "hybrid", or "terrain"
image_width (integer): Width in pixels, max 640. Default: 640
image_height (integer): Height in pixels, max 640. Default: 640
scale (integer): 1 (default) or 2 for high-DPI/retina displays
zoom (integer): Zoom level 0-21. Auto-calculated if omitted.
marker_color (string): Default color for all markers (overridden by per-point color)
marker_size (string): Default size for all markers (overridden by per-point size)
draw_path (boolean): Set true to draw a line connecting points in order. Requires at least 2 points.
path_color (string): Path line color in hex (e.g., "0xFF0000"). Default: "0x0000ff"
path_weight (integer): Path line thickness in pixels, 1-20. Default: 5

Example - Basic markers:

{
  "action": "create_map",
  "points": [
    {"latitude": 37.4220, "longitude": -122.0841, "label": "A"},
    {"latitude": 37.4275, "longitude": -122.1697, "label": "B"}
  ]
}

Example - Styled markers with path on satellite view:

{
  "action": "create_map",
  "points": [
    {"latitude": 37.7749, "longitude": -122.4194, "label": "A", "color": "red"},
    {"latitude": 37.3382, "longitude": -121.8863, "label": "B", "color": "blue"}
  ],
  "draw_path": true,
  "path_color": "0xFF0000",
  "map_type": "hybrid"
}

Example - Multiple locations with global marker styling:

{
  "action": "create_map",
  "points": [
    {"latitude": 40.7128, "longitude": -74.0060},
    {"latitude": 34.0522, "longitude": -118.2437},
    {"latitude": 41.8781, "longitude": -87.6298}
  ],
  "marker_color": "green",
  "marker_size": "mid",
  "map_type": "terrain",
  "image_width": 600,
  "image_height": 400
}

Response

The response includes:

signed_url -- Link to the generated map image. Always present this to the user.
image_base64 -- Base64-encoded PNG for inline rendering
file_id -- Storage identifier for the image
size_bytes -- Image file size
points_count -- Number of markers plotted
map_type, size, scale, zoom, draw_path -- Confirms the settings used

Important Notes

Use latitude/longitude coordinates for best reliability.
Labels only display on default or mid-size markers. Tiny and small markers cannot show labels.
When draw_path is enabled, at least 2 points are required.
If zoom is omitted, the map auto-fits to show all markers.
Maximum image dimensions are 640x640 pixels (before scale multiplier).
Generated map images are available for 7 days via the signed URL.

Frequently Asked Questions

How do I connect this tool to an external agent?

You can install the local MCP server by opening a terminal and running:

Install commands

npm install -g @agentpmt/mcp-router
agentpmt-setup

This will connect you to local agents like Claude Code, Windsurf, Grok Build, Cursor, etc.

Alternatively you can connect to the hosted version with this config block, no installation required:

Hosted MCP config

{
  "mcpServers": {
    "agentpmt": {
      "type": "streamable-http",
      "url": "https://api.agentpmt.com/mcp",
      "headers": {
        "Authorization": "Bearer <AGENTPMT_BEARER_TOKEN>",
        "x-instance-metadata": "{\"client\":\"generic-mcp\",\"platform\":\"remote\"}"
      }
    }
  }
}

View MCP Connection Instructions for more details.

How does an external agent use this tool?

After the external agent is connected to an Agent Group that can use this tool, paste this prompt into the agent:

Agent prompt

Use the AgentPMT-Tool-Search-and-Execution tool. First call action 'get_instructions' so you know how to use the tool search interface. Then call action 'get_schema' with tool_id 695e8767c309cf48479329e6 ("Map Generator With Markers"). After reading the schema and any returned instructions, tell me what this tool can do, we are going to be using it

The agent should fetch the tool schema first, collect the required parameters for your request, and then call the tool through AgentPMT.
